The L296 is a high current step-down Power Switching Regulator delivering 4A at a voltage variable from 5.1 to 40V. It features of the devices include soft start, remote inhibit and thermal protection, a reset output for microprocessors and a PWM comparator input for synchronization in multichip configurations. An efficient operation at switching frequencies up to 200KHz allows a reduction in the size of external filter components. A voltage sense input and SCR drive output are provided for optional crowbar overvoltage protection with an external SCR.



    Very few external components

    Reset output

    Control circuit for crowbar SCR

    Input for remote inhibit and synchronous PWM

    Thermal shutdown
