Termometre, Higrometre, TermostateTermostate cu bimetalTermostat bimetalic, 70C, NO, BT-67F070
BT-67F070 Termostat bimetalic In carcasa, gama 70C/50C
Senzor:termostat; Config.iesire:NO; Tdesch:50C; Tinch:70C; 1A
Tip senzor termostat
Caracteristici orificiu de montare Ø 3,6 mm
Curent de lucru max. 1 A
Tensiune de lucru max. 120 V AC
Dimensiuni exterioare 10,2 x 4,6 x 30 mm
Simbol Toleranta Config. iesire Temp. desch. Temp. inch.
[C] [C]
BT-67L050 ±4C NC 50 30
BT-67L070 ±4C NC 70 50
BT-67L080 ±6C NC 80 55
BT-67L090 ±6C NC 90 60
BT-67L100 ±6C NC 100 70
BT-67L110 ±6C NC 110 80
BT-67F070 ±4C NO 50 70
BT-67F090 ±6C NO 60 90
BT-67F110 ±6C NO 80 110
