Furnizor: HONEYWELL S&C
SS49E

RoHS : Da
Descriere
SENSOR, HALL EFFECT, LINEAR
Sensor Terminals:Pin
Min Output Voltage:1.0mV
DC Supply Voltage Range:3V to 6.5V
Output Configuration:Source
Sensor Housing:Rectangular
Switching Speed:3µs
Contact Configuration:Radial Lead IC
Input Current:10mA
Max Operating Temperature:100C
Max Output Voltage:1.75mV
Max Supply Voltage:6.5V dc
Max Supply Voltage DC:6.5V
Min Supply Voltage:3.0V dc
Min Temperature Operating:-40C
No. of Pins:3
Output Current:1.0mA
Response Time:3µs
Sensor Type:Hall-Effect Linear Position Sensor
Series:SS49E
Supply Current:6mA
Termination Type:Through Hole
