SenzoriSenzori presiune, traductoare de presiuneSenzor de presiune, diferential, 0-100kpa, MPX5100DP, NXP Semiconductors
SenzoriSenzori presiune, traductoare de presiuneSenzor de presiune, diferential, 0-100kpa, MPX5100DP, NXP Semiconductors
Producător : NXP (FREESCALE)
Tip senzor : de presiune
Domeniu de măsură : 0...100kPa
Mod de acţionare : diferenţial
Configuraţie ieşire : analogică de tensiune
Tensiune alimentare : 4.75...5.25V DC
Manufacturer: NXP
Product Category: Board Mount Pressure Sensors
RoHS: Details
Operating Pressure: 14.5 psi
Pressure Type: Differential
Accuracy: 2.5 %
Mounting Style: Through Hole
Port Type: Dual Radial Barbed
Package/Case: Unibody 6-pin
Operating Supply Voltage: 5 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Packaging: Tray
Output Voltage: 4.7 V
Series: MPX5100
Brand: NXP Semiconductors
Port Size: 4.93 mm
Operating Supply Current: 7 mA
Product Type: Pressure Sensors
Subcategory: Sensors
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
