VISHAY DALE - LVR035L000FE70 - RESISTOR, PRECISION, 0.005 OHM 1%

Furnizor: VISHAY DALE

LVR035L000FE70

RoHS : Da
Descriere
RESISTOR, PRECISION, 0.005 OHM 1%
Resistance:0.005ohm
Resistance Tolerance:± 1%
Power Rating:3W
Voltage Rating:0.12V
Series:LVR03
Temperature Coefficient:± 1000ppm/C
Resistor Element Type:Wirewound
No. of Pins:2
Body Diameter:5.21mm
Package / Case:Axial
Temperature Coeff. +:1000ppm/C
Temperature Coeff. -:1000ppm/C
Tolerance +:1%
Tolerance -:1%
Body Length:14.22mm
Insulation Resistance:10000Mohm
Lead Diameter:0.813mm
Operating Temperature Max:175C
Operating Temperature Range:-65C to +175C
Temperature Operating Min:-65C
Dielectric Strength VAC:1000V
Weight:2g

ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
