Componente electronice pasiveRezistenteRezistente de precizie, 0.1%, 0.01%Rezistenta 0.01R, de putere, 5% 25W, THS25R01J
Furnizor: TYCO ELECTRONICS
RoHS : Da
Descriere
RESISTOR, AL CLAD, 25W R01 5%
Resistance:0.01ohm
Resistance Tolerance:± 5%
Power Rating:12.5W
Voltage Rating:550V dc
Series:THS25
Temperature Coefficient:± 50ppm/C
Resistor Element Type:Wirewound Aluminium Clad
Resistor Case Style:Axial
No. of Pins:2
Case Style:Axial
External Length / Height:15mm
Temperature Coeff. +:50ppm/C
Temperature Coeff. -:50ppm/C
Tolerance, +:5%
Tolerance, -:5%
Voltage Rating DC:550V
Body Length:29mm
External Width:28mm
Full Power Rating Temperature:25C
Insulation Resistance:10000Mohm
Lead Length:10mm
Max Operating Temperature:110C
Min Temperature Operating:-25C
Operating Temperature Range:-25C to +110C
Power Rating with Heatsink:25W
Voltage Rating AC:550V
Dielectric Strength, VAC:2500V
Fixing Hole Diameter:3.3mm
Length:51.8mm
Working Voltage:550V
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
