Furnizor: IMO PRECISION CONTROLS
SRKE-1AT-SL-24VDC
RoHS : Da
Descriere
RELAY, SPNO, 24VDC
Nom Coil Voltage DC:24V
Contact Current Max:45A
Contact Voltage DC Nom:14V
Coil Resistance:362ohm
Contact Configuration:SPNO
Relay Mounting:PC Board
External Length / Height:22.3mm
External Width:26.5mm
External Depth:22mm
Max Contact Current DC:45A
Max Contact Voltage DC:30V
Max Operating Temperature:125C
Min Temperature Operating:-40C
Mounting Type:PCB
No. of Poles:1
Series:SRK
Contact Resistance:100mohm
DC Coil Power:1.6W
Insulation Resistance:50Mohm
