Releu 5V, SPST-NO, 8A, DC5, G6RN-1A-5, OMRON

G6RN-1A-5 Releu SPST-NO, 8A, DC5/18,3mA, montare PCB   RoHS

Furnizor:  OMRON ELECTRONIC COMPONENTS

Descriere
RELAY, PCB, SPNO, 5VDC
Relay Type:Power
Coil Voltage VDC Nom:5V
Contact Current Max:8A
Contact Voltage AC Nom:250V
Contact Voltage DC Nom:30V
Coil Resistance:114ohm
Contact Configuration:SPNO
Coil Type:DC Coil
Coil Current:44mA
Nom Operating Power:220mW
Relay Mounting:PC Board
External Length / Height:15.3mm
External Width:28.8mm
External Depth:10.5mm
Contact Current AC Max:8A
Contact Current DC Max:5A
Contact Voltage AC Max:240V
Contact Voltage DC Max:30V
Mounting Type:PCB
No. of Poles:1
Operating Temperature Max:85C
Series:G6RN
Temperature Operating Min:-40C
Approval Bodies:CSA and VDE
Approval Category:UL Recognised
Coil Operating Lower Percent Limit:70%
Coil Operating Upper Percent Limit:110%
Contact Material:AgNi
Contact Plating:Gold
DC Coil Power:220mW
Operating Time:15ms
Release Time:5ms
Switch Current Max:8A
Switching Power Max:2000VA
Weight:9g
