Manufacturer OMRON OCB
Type of relay electromagnetic
Contacts configuration DPDT
Rated coil voltage 12V DC
Contact current max. 2A
AC contacts rating @R (at resistive load)0.5A / 125V AC
DC contacts ratig @R
(at resistive load) 2A / 30V DC
Switched voltage max. 125V AC, max. 125V DC
Relay variant miniature
Mounting PCB
Coil resistance 288Ω
Operate time 7ms
Body dimensions 20.5x10.1x11.5mm
Release time 3ms
Coil power consumption 500mW
Operating temperature -25...70°C
Relay series G5V-2
Contact resistance 50mΩ
Terminal pitch 5mm
Coil current 41.7mA
Contact plating gold-plated
