Releu 5VDC, SPDT, 15A, 32.21.7.005.2000, FINDER

Furnizor:  FINDER

32.21.7.005.2000

RoHS :  Da
Descriere
RELAY, PCB, 5VDC
Relay Type:Subminiature
Coil Voltage VDC Nom:5V
Contact Current Max:15A
Contact Voltage AC Nom:250V
Coil Resistance:125ohm
Coil Type:DC Coil, Sensitive
Coil Current:40mA
Nom Operating Power:200mW
Relay Mounting:PC Board
External Width:20mm
External Depth:10mm
Contact Configuration:SPDT
Contact Current AC Max:6A
Contact Voltage AC Max:400V
External Length / Height:10.7mm
Mounting Type:PCB
No. of Poles:1
Operating Temperature Max:85C
Operating Temperature Min:-40C
Series:32
Type:Wash Tight
Approval Bodies:GOST, VDE
Approval Category:UL Recognised
Contact Material:AgCdO
Contact Type:CO
Current Rating:6A
DC Coil Power:200mW
Dielectric Voltage Coil to Contact:1000VAC
No. of Electrical Operations:100000
No. of Mechanical Operations:20000000
No. of Pins:5
Operating Time:6ms
Release Time:4ms
Single Cycle Surge Current:15A
Voltage Rating VAC:250V
