TE CONNECTIVITY - PCJ-124D3M - RELAY, PCB, SPNO, 24VDC
Relay Type: General Purpose
Coil Voltage VDC Nom: 24V
Contact Current Max: 3A
Contact Voltage AC Nom: 240V
Coil Resistance: 2.88kohm
Contact Configuration: SPNO
Coil Type: DC Monostable
Nom Operating Power: 200mW
Relay Mounting: Through Hole
External Height: 15mm
External Width: 20.4mm
External Depth: 7mm
Approval Bodies: VDE
Approval Category: UL Recognised
Contact Current AC Max: 3A
Contact Material: AgNi
Contact Resistance: 100mohm
Contact Voltage AC Max: 400V
DC Coil Power: 200mW
Dielectric Strength VAC: 4000VAC
Dielectric Voltage Coil to Contact: 4000VAC
Dielectric Voltage Contact to Contact: 750VAC
External Length / Height: 15mm
Insulation Resistance: 1000Mohm
Mechanical Life: 5,000,000 Operations
Mounting Type: PCB
Must Actuate Voltage: 18VDC
Must Release Voltage: 1.2VDC
No. of Mechanical Operations: 5000000
No. of Poles: 1
Operating Temperature Max: 90°C
Operating Temperature Min: -40°C
Operating Time: 10ms
Release Time: 4ms
Series: PCJ
Weight: 4g
