Relee și contactoare, socluriRelee electromagneticeReleu 24VDC, SPDT, 16A, ALZ12F24, PANASONIC
Relee și contactoare, socluriRelee electromagneticeReleu 24VDC, SPDT, 16A, ALZ12F24, PANASONIC
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 16 A
Switching Voltage440VAC - Max
Coil Current 16.7 mA
Coil TypeNon Latching
Features-
Termination Style PC Pin
Seal RatingSealed - Fully
Coil Insulation Class F
Must Operate Voltage 16.8 VDC
Must Release Voltage 2.4 VDC
Operate Time 15 ms
Release Time 5 ms
Operating Temperature -40°C ~ 105°C
Contact MaterialSilver Tin Oxide (AgSnO)
Relay Type General Purpose
Coil Resistance 1.44 kOhms
Base Product Number ALZ12F
