Pagină de start>Relee și contactoare, socluri>Relee electromagnetice>Releu 24VAC. 8A, DPDT, RT424524, TYCO

Mareste

Releu 24VAC. 8A, DPDT, RT424524, TYCO

Denumire Produs: RT424524

COD: 52846

Preț orientativ: 54,16 RON

RT424524 Releu DPDT, 8A, AC24V  RoHS
Producator: TYCO Simbol original: 7-1393243-6


  •   RELAY, PCB, DPCO, 24VAC
  • Relay Type: General Purpose
  • Coil Voltage VAC Nom: 24V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • Coil Resistance: 350ohm
  • Contact Configuration: DPCO
  • Coil Type: AC Monostable
  • Nom Operating Power: 0.76VA
  • Relay Mounting: Through Hole
  • External Height: 15.7mm
  • External Width: 29mm
  • External Depth: 12.7mm
  • AC Coil Power: 0.76VA
  • Approval Bodies: BEAB, CSA, VDE
  • Approval Category: UL Recognised
  • Contact Material: AgNi 90/10
  • Contact Voltage AC Max: 24V
  • Current Rating: 8A
  • Dielectric Voltage Coil to Contact: 5000V
  • Dielectric Voltage Contact to Contact: 1000V
  • External Length / Height: 15.7mm
  • Lead Spacing: 5mm
  • Mounting Type: PCB
  • No. of Pins: 8
  • No. of Poles: 2
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Operating Time: 7ms
  • Release Time: 2ms
  • Row Pitch: 7.5mm
  • Series: RT2
  • Switching Power Max: 2000VA
  • Switching Voltage Max: 400VAC
  • Voltage Rating V AC: 250VAC
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
