Relee și contactoare, socluriRelee electromagneticeReleu 12VDC, 16A, SPDT, LM1H-12D, RAYEX ELECTRONIC
Relee și contactoare, socluriRelee electromagneticeReleu 12VDC, 16A, SPDT, LM1H-12D, RAYEX ELECTRONIC
Manufacturer RAYEX ELECTRONIC
Relay type electromagnetic
Contacts configuration SPDT
Rated coil voltage 12V DC
AC contacts rating
(at resistance load) 16 A / 250 VAC
DC contacts rating
(at resistance load) 16 A / 30 VDC
Contact current max. 16A
Switched voltage max 250V AC, max 30V DC
Relay variant miniature
Mounting PCB
Coil resistance 270Ω
Operate time 15ms
Body dimensions 29.4 x 12.5 x 25.5mm
Release time 10ms
Coil power consumption 530mW
Operating temperature -40...80°C
Relay series LM1
Contact resistance 100mΩ
Contact material AgCdO
Contacts pitch 5mm
Coil current 44.4mA
