Coil Type Non Latching
Coil Current 33,3mA
Coil Voltage 120VAC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 30A
Switching Voltage 277VAC - Nom
Turn On Voltage (Max) 96 VAC
Turn Off Voltage (Min) 12 VAC
Operate Time 15ms
Release Time 15ms
Features Insulation - Class F
Mounting Type Chassis Mount
Termination Style Quick Connect - 0.250" (6.3mm)
Operating Temperature -55°C ~ 65°C
Contact Material Silver Cadmium Oxide (AgCdO)
Coil Power 4 VA
Coil Resistance 950 Ohms
