Comutatoare, întrerupătoare, basculanteButoane Push, TactilePush buton, tach smd, 6x6mm, OFF-(ON), B3SN-3012, OMRON
Producator: OMRON ELECTRONIC COMPONENTS
Contact Configuration: SPST-NO
Operating Force: 1.57N
Contact Voltage DC Nom: 24V
Contact Current Max: 50mA
Actuation Type: Top
Switch Terminals: Surface Mount
Actuator / Cap Colour: Black
Contact Configuration: SPST-NO
Contact Current : Contact Voltage DC Max: 50mA
Contact Current : Contact Voltage DC Min: 1mA
Contact Current DC Max: 50mA
Contact Current Max: 50mA
Contact Resistance: 100mohm
Contact Resistance Max: 100mohm
Contact Voltage DC Max: 24VDC
Contact Voltage DC Nom: 24V
Dielectric Strength VAC: 250VAC
External Depth: 6mm
External Length / Height: 3.1mm
External Width: 7mm
Insulation Resistance: 100Mohm
No. of Mechanical Operations: 100000
No. of Poles: 1
Operating Force Max: 1.57N
Operating Temperature Max:
Operating Temperature Min:
Pre-travel: 0.25mm
Resistive Current Rating: 50mA
Return Force Min: 30gf
Series: B3SN
Switch Operation: SPST N/O
Terminal Type: SMD
Termination Type: SMD
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.Norul de tag-uri
