TAIWAN SEMICONDUCTOR - GBU604 - BRIDGE RECTIFIER, 6A, 400V

•  BRIDGE RECTIFIER, 6A, 400V
• No. of Phases: Single
• Repetitive Reverse Voltage Vrrm Max: 400V
• Forward Current If(AV): 6A
• Forward Voltage VF Max: 1V
• Diode Mounting Type: Through Hole
• Operating Temperature Range: -55°C to +150°C
• Bridge Rectifier Case Style: GBU
• No. of Pins: 4
• Body Height Max: 18.8mm
• Current If @ Vf: 6A
• Current Ir Max: 5µA
• Current Temperature: 25°C
• Device Marking: GBU604
• Diode Type: Bridge Rectifier, Single Phase
• External Depth: 3.56mm
• External Length / Height: 18.8mm
• External Width: 22.3mm
• Flammability Rating: UL94V-0
• Forward Surge Current Ifsm Max: 175A
• Junction Temperature Tj @ Irrm: 25°C
• Junction Temperature Tj Max: 150°C
• Junction Temperature Tj Min: -55°C
• Junction to Case Thermal Resistance A: 2°C/W
• Operating Temperature Max: 150°C
• Operating Temperature Min: -55°C
• Output Current Max: 6A
• Package / Case: GBU
• RMS Input Voltage: 280V
• Termination Type: Through Hole
• Voltage Rating V AC: 280V
