Potentiometru de putere, 5K, 2W, industrial, LONG LIFE, RV4NAYSD502A, ETI Systems

Denumire Produs: RV4NAYSD502A, ETI Systems

COD: 63554


Preț: 149,00 RON

(Prețul include TVA)
Stoc Limitat
 Product Category: Potentiometers

RoHS: RoHS Compliant Details
Product: MIL Style Potentiometer
Number of Gangs: 1 Gang
Resistance: 5KOhms
Taper: Linear
Power Rating: 2 W
Voltage Rating: 500 V
Tolerance: 10 %
Termination Style: Solder Lug
Element Type: Carbon
Number of Turns: 1 Turn
Shaft Type: Slotted
Type: Rotary Metal
Shaft Diameter: 0.249 in
Shaft Length: 0.875 in
Series: RV4
Brand: ETI Systems
Diameter: 1.12 in
Height: 0.536 in
Operating Temperature Range: - 65 C to + 125 C


The RV4NAYSD502A is a 2W Potentiometer up to 5kohm resistance with solder lug terminals. It is military qualified potentiometer made in accordance to MIL-PRF-94 specifications.

    Conductive plastic element
    Robust nickel-plated brass shaft and bushings
    Linear taper
    25000-cycle rotational life
    9.53mm (0.375") x 32 NEF-2A bushing thread
    Slotted shaft ending
    Ø27.8mm (1.094") maximum except at terminal standoff body
    500V maximum working voltage
    312° Mechanical rotation

Aplicaţii

Automotive, Industrial, Communications & Networking, Aerospace, Defence, Military, Automation & Process Control




ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
