Placa dezvoltare, ATmega328, ARDUINO UNO, A000073, ARDUINO

Denumire Produs: ARDUINO UNO, A000073

COD: 77834

Preț: 180,90 RON

(Prețul include TVA)

Stoc Limitat

Adaugati la lista de favorite

Cantitate:

Descriere
Data Sheet
Recenzii
Etichete
Trimiteti unui prieten
Am găsit o greşeală

ARDUINO - A000073 - ATMEGA328, ARDUINO UNO SMD, DEV KIT

ATMEGA328, ARDUINO UNO SMD, DEV KIT

Silicon Manufacturer: Atmel

Core Architecture: AVR

Core Sub-Architecture: megaAVR

Silicon Core Number: ATmega328

Silicon Family Name: ATmega

No. of Bits: 8bit

Kit Contents: Dev Board for ATmega328 MCU

Arduino Uno SMD Rev3 Development Board

The A000073 is a Arduino Uno SMD R3 development board based on the ATmega328 microcontroller. The ATmega328 is a low power CMOS 8bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega328 achieves throughputs approaching 1MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. The Arduino Uno SMD R3 evaluation board has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, a 16MHz crystal oscillator, a USB connection, a power jack, an ICSP header and a reset button. It contains everything needed to support the microcontroller, simply connect it to a computer with a USB cable or power it with a AC to DC adapter or battery to get started. The Uno differs from all preceding boards in that it does not use the FTDI USB to serial driver chip.

ATmega16U2 instead 8U2 as USB to serial converter

Stronger RESET circuit

1.0 pinout

Input voltage (recommended) range from 7V to 12V

5V operating voltage

32KB flash memory

0.5KB flash memory for bootloader

50mA of DC current for 3.3V pin

1KB EEPROM

2KB SRAM

Embedded Design & Development

Building Automation

Industrial

Sensing & Instrumentation

Automation & Process Control
