Mufa BNC, panou, mama, 50 ohmi, standard militar, 4 GHz, 5-1634523-1

Denumire Produs: 5-1634523-1, TE CONNECTIVITY

COD: 82785

Preț orientativ: 19,94 RON

Descriere
Recenzii
Etichete
Trimiteti unui prieten
Am găsit o greşeală

TE CONNECTIVITY 5-1634523-1 RF / Coaxial Connector, BNC Coaxial, Straight Bulkhead Jack, Solder, 50 ohm, Brass

Nominal impedance of 50 ohm

Maximum VSWR is 1.15 at 2GHz

Phosphor bronze with gold plated contacts

Temperature rating is -55°C to 85°C

Body material is zinc

Interface meets MIL STD348A standard

Connector Type BNC Coaxial

Connector Body Style Straight Bulkhead Jack

Coaxial Termination Solder

Impedance 50ohm

Coaxial Cable Types -

Contact Material Brass

Contact Plating Gold Plated Contacts

Frequency Max 4GHz

Connector Mounting Panel Mount

ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
