Modul USB, Wifi, 802.11b/g/n, RTl8192/8188CUS Chipset, 814, ADAFRUIT

Descriere
Recenzii
Etichete
Trimiteti unui prieten
Am găsit o greşeală

RTl8192/8188CUS Chipset

Sticks out 8mm (0.3") beyond USB port

Weight: 2.17g

Wireless Standards: IEEE 802.11n (draft), IEEE 802.11g, IEEE 802.11b

Host Interface: High speed USB2.0/1.1 interface

Data Rate: 802.11n: up to 150Mbps (downlink) and up to 150Mbps (uplink) , 802.11g: 54 / 48 / 36 / 24 / 18/ 12 / 9 / 6 Mbps auto fallback, 802.11b: 11 / 5.5 / 2 / 1 Mbps auto fallback

Frequency Band: 2.4GHz ISM (Industrial Scientific Medical) Band

Chipset: Realtek

RF Frequency: 2412 ~ 2462 MHz (North America), 2412 ~ 2472 MHz (Europe), 2412 ~ 2484 MHz (Japan)

Radio Channel: 1 ~ 14 channels (Universal Domain Selection)

Antenna Type: Integrated Antenna

Roaming: Full mobility and seamless roaming from cell to cell

RF Output Power: 13 ~17 dBm (Typical)

Modulation: 11n: BPSK, QPSK, 16QAM, 64QAM with OFDM, 11g: BPSK, QPSK, 16QAM, 64QAM, OFDM, 11b: DQPSK, DBPSK, DSSS, CCK

Data Security: 64/128-bit WEP Encryption

WPA, WPA-PSK, WPA2, WPA2-PSK. TKIP/AES

Network: Auto-switch to use 802.11n or 802.11g or 802.11b mode

Supports Ad-Hoc, Infrastructure WLAN network, Wireless roaming, Data rate auto fall-back under noisy environment or longer range distance, Site Survey with Profile function

Configuration & Management: Plug-and-Play setup and installation, Management Utility supports 2000 / XP/ Vista

Media Access Control CSMA/CA with ACK

LED Indicator Link/Active ( Blue )

Operating Temperature 0°C to 40°C

Storage Temperature -20°C to 75°C

Operating Humidity 10% ~ 90% (Non Condensing)

Storage Humidity 5% ~ 95% (Non Condensing)

Requirements: Available USB 2.0 port

TUTORIAL CU ACEST MODUL
