STM32 Nucleo-144 development board with STM32L4R5ZI MCU, SMPS, supports Arduino, ST Zio and morpho connectivity. It provides an affordable and flexible way for users to try out new concepts and build prototypes by choosing from the various combinations of performance and power consumption features provided by the STM32 microcontroller. For the compatible boards the SMPS significantly reduces power consumption in run mode. The ST Zio connector extends the Arduino™ Uno V3 connectivity and the ST morpho headers provide an easy means of expanding the functionality of the Nucleo open development platform with a wide choice of specialized shields.



USB OTG or full-speed device (depending on STM32 support)

3 user LEDs, 2 user and reset push-buttons, 32.768KHz crystal oscillator

USB with Micro-AB, SWD, Ethernet RJ45 (depending on STM32 support) (board connectors)

ST Zio connector including Arduino™ Uno V3, ST morpho (board connectors)

ST-LINK USB VBUS or external sources flexible power-supply options

On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability

Comprehensive free software libraries and examples available with the STM32Cube package

Support of a wide choice of IDEs including IAR™, Keil®, GCC-based IDEs, Arm® M
