J113, JFET Transistor, -35 V, -3 V, TO92, ON SEMICONDUCTOR

Descriere
Data Sheet
Recenzii
Etichete
Trimiteti unui prieten
Am găsit o greşeală

Furnizor: FAIRCHILD SEMICONDUCTOR
J113

RoHS : Da

Descriere
TRANSISTOR, JFET, N, TO-92
Transistor Type:JFET
Breakdown Voltage V(br)gss:-35V
Zero Gate Voltage Drain Current Range Idss:2mA
Gate-Source Cutoff Voltage Vgs(off) Max:3V
Power Dissipation:625mW
Transistor Case Style:TO-92
No. of Pins:3
Application Code:SW
Current Idss Max:2mA
Current Idss Min:2mA
Current Ig:50mA
Device Marking:J113
Drain Source Voltage Vds:35V
Full Power Rating Temperature:25C
No. of Transistors:1
Package / Case:TO-92
Pin Configuration:m
Pin Format:m
Power Dissipation Ptot Max:0.35W

Termination Type:Through Hole
