IR2113S, MOSFET Driver, High Side and Low Side, 10V-20V supply, 2.5A output, INFINEON

Denumire Produs: IR2113S

COD: 58552

Preț orientativ: 27,73 RON

INTERNATIONAL RECTIFIER - IR2113S - DRIVER, MOSFET HIGH/LOW, SMD, 2113

  • DRIVER, MOSFET HIGH/LOW, SMD, 2113
  • Device Type: High Side / Low Side
  • Module Configuration: High Side / Low Side
  • Peak Output Current: 2.5A
  • Input Delay: 120ns
  • Output Delay: 94ns
  • Supply Voltage Range: 10V to 20V
  • Driver Case Style: SOIC
  • No. of Pins: 16
  • Operating Temperature Range: -40°C to +125°C
  • MSL: MSL 3 - 168 hours
  • Base Number: 2113
  • IC Generic Number: 2113
  • Logic Function Number: 2113
  • No. of Outputs: 2
  • Offset Voltage: 600V
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -40°C
  • Output Current: 2.5A
  • Output Sink Current Min: 2000mA
  • Output Source Current Min: 2000mA
  • Output Voltage: 620V
  • Output Voltage Max: 20V
  • Output Voltage Min: 10V
  • Package / Case: SOIC
  • Power Dissipation Pd: 1.25W
  • Supply Voltage Max: 20V
  • Supply Voltage Min: 10V
  • Termination Type: SMD
  • Turn Off Time: 94ns
  • Turn On Time: 120ns



ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
