DAC08EN Adaptor: D/A; 8bit; 11,8Msps; Canale:1; DIP16
- IC, DAC, 8BIT, 11.8MSPS, DIP-16
- Resolut
- Resolution (Bits): 8bit
- Sampling Rate: 11.8MSPS
- Input Channel Type: Parallel
- Supply Voltage Range: ± 4.5V to ± 18V
- Digital IC Case Style: DIP
- No. of Pins: 16
- Data Interface: Parallel
- Supply Current: -6.5mA
- Operating Temperature Range: 0°C to +70°C
- A/D / D/A Features: Multiplying
- Base Number: 08
- Conversion Time: 0.15µs
- IC Case Style: DIP
- IC Generic Number: 08
- IC Temperature Range: Commercial
- Input Type: Parallel
- Linearity Error: 0.5%
- Linearity Error ADC / DAC +: 0.5LSB
- Linearity Error ADC / DAC -: 0.5LSB
- Logic Function Number: 08
- No. of Bits: 8
- No. of Channels: 1
- Operating Temperature Max: 70°C
- Operating Temperature Min: 0°C
- Package / Case: DIP
- Power Dissipation Ptot Max: 174mW
- Sample Rate: 11.8MSPS
- Settling Time: 0.15µs
- Supply Voltage Range - Analogue: ± 4.5V to ± 18V
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
