•   IC, 8BIT DAC, DIP16, 800
• Resolution (Bits): 8bit
• Input Channel Type: Parallel
• Supply Voltage Range: ± 4.5V to ± 18V
• Digital IC Case Style: DIP
• No. of Pins: 16
• Data Interface: CMOS, Parallel, TTL
• Supply Current: 2.5mA
• Operating Temperature Min: 0°C
• Operating Temperature Max: 70°C
• MSL: MSL 1 - Unlimited
• A/D / D/A Features: Multiplying
• Base Number: 0800
• Conversion Time: 2µs
• Device Marking: DAC0800
• IC Case Style: DIP
• IC Generic Number: 0800
• IC Temperature Range: Commercial
• Input Type: Parallel
• Linearity Error: 0.5%
• Linearity Error ADC / DAC +: 0.5LSB
• Linearity Error ADC / DAC -: 0.5LSB
• Logic Function Number: 800
• No. of Bits: 8
• No. of Channels: 1
• No. of DACs: 1
• Operating Temperature Range: 0°C to +70°C
• Output Type: Current
• Power Dissipation Ptot Max: 174mW
• Settling Time: 0.15µs
• Supply Voltage Max: 18V
• Supply Voltage Min: 4.5V
• Supply Voltage Range - Analogue: ± 4.5V to ± 18V
