Contactor 230VAC, 25A, 3PNO, auxiliar 1xNO, AC3, LH1-D2510, ELECTRIX

Denumire Produs: LH1-D2510

COD: 83924

Preț orientativ: 141,36 RON

Descriere
Data Sheet
Recenzii
Etichete
Trimiteti unui prieten
Am găsit o greşeală

Technical specifications LH1-D

Operation class: AC3, 25A

Rated operating voltage of power contacts Un (V): UP TO 690VAC

Surge voltage wear resistance Uimp(V): 6000

Rated voltage of the coil Uc(V): 230VAC

Limits of the controlling coil voltage: 0.8-1.15U

Electrical wear resistance (number of cycles): 200000

Mechanical wear resistance (number of cycles): 500000

Number of cycles per hour: 500

Power consumption of coil(VA): 7

Rated current In(A): 25A

Connecting: RIGID OR FLEXIBLE CONDUCTORS

Mounting: DIN RAIL

Plastic box: RESISTENCE UV, NONFAMABLE

Ambient temperature: -10/+65c

ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
