BULGIN - PX0410/12S/6065 - SOCKET, FREE, 12WAY

PLUG, FREE, 12WAY

• Connector Type: Circular Industrial
• Series: Micro Buccaneer
• Gender: Plug
• Contact Gender: Pin
• Connector Mounting: Cable
• No. of Contacts: 12
• Contact Material: Copper
• Contact Plating: Gold
• Cable Diameter Max: 6.5mm
• Cable Diameter Min: 6.0mm
• Connector Mounting Orientation: Cable
• Connector Type: Circular
• Contact Material: Copper Alloy
• Contact Plating: Gold
• Contact Resistance: 5mohm
• Contact Type: Pin
• Current Rating: 1A
• Flammability Rating: UL94V-0
• IP / NEMA Rating: IP68
• Insulation Resistance: 10Mohm
• Material: Polyamide
• Mounting Type: Cable
• No. of Poles: 12
• No. of Ways: 12
• O Ring Material: Nitrile
• Operating Temperature Max: 80C
• Operating Temperature Min: -40C
• Voltage Rating V AC: 50V
• Wire Size AWG Max: 24AWG
• Wire Size AWG Min: 28AWG
• Working Voltage: 50V

  ACCESORII : PINUL MAMA PT MUFA - OPTIONAL
