Furnizor: PANASONIC
EEUFC0J561
RoHS : Da
Descriere
CAPACITOR, 560UF, 6.3V
Capacitance:560µF
Capacitance Tolerance:± 20%
Voltage Rating:6.3VDC
Life Time @ Temperature:3000 hours @ 105C
Height:11.5mm
Diameter:8mm
Capacitor Case Style:Radial
Capacitor Mounting:Through Hole
Lead Spacing:3.5mm
Operating Temperature Range:-55C to +105C
AC Ripple Current:555mA
External Length / Height:11.5mm
Impedance:0.117ohm
Impedance Frequency:100kHz
Impedance Temperature:20C
Lead Diameter:0.6mm
No. of Pins:2
Operating Life Temperature:105C
Operating Lifetime:3000h
Operating Temperature Max:105C
Operating Temperature Min:-55C
Package / Case:Radial
Ripple Current Frequency:100kHz
Ripple Current Temperature:105C
Series:FC
Terminal Type:Wire Ended
Tolerance +:20%
Tolerance -:20%
Voltage Rating VDC:6.3V
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
