Componente electronice pasiveCondensatori electrolitic, smd, ceramici, multistrat, low esr, bipolar, MKP, MKTCondensatori electroliticiCondensatori electrolitici LOW ESR1500uF/10V, electrolitic, Low Esr, RM5, 10x23mm, Rubycon
Furnizor: RUBYCON -JAPAN
RoHS : Da
Descriere
CAPACITOR, 1500UF, 10V
Capacitor Dielectric Type:Aluminium Electrolytic
Capacitance:1500µF
Capacitance Tolerance:± 20%
Voltage Rating:10V dc
Series:ZL
Height:23mm
Outside Diameter:10mm
Capacitor Case Style:Radial Leaded
No. of Pins:2
Mounting Type:Through Hole
Lead Spacing:5mm
Operating Temperature Range:-40C to +105C
AC Ripple Current:2150mA
Application:High Temperature
Body Diameter:10mm
Case Style:Radial
External Length / Height:23mm
Impedance:0.022ohm
Impedance Frequency:100kHz
Impedance Temperature:20C
Lead Diameter:0.6mm
Leakage Current:150µA
Max Operating Temperature:105C
Min Temperature Operating:-40C
Operating Lifetime:4000h
Ripple Current Frequency:100kHz
Ripple Current Temperature:105C
Terminal Type:Wire Ended
Tolerance, +:20%
Tolerance, -:20%
Voltage Rating DC:10V
ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
