Pagină de start>Componente electronice pasive>Condensatori electrolitic, smd, ceramici, multistrat, low esr, bipolar, MKP, MKT>Condensatori electrolitici>Condensatori electrolitici LOW ESR>680uF/250V, electrolitic RM10, low esr, 30x37mm, Cornell Dubilier

Mareste

680uF/250V, electrolitic RM10, low esr, 30x37mm, Cornell Dubilier

Denumire Produs: 381LR681M250K032, Cornell Dubilier

COD: 66169

Preț orientativ: 93,93 RON

Manufacturer: Cornell Dubilier

Product Category: Aluminum Electrolytic Capacitors - Snap In
RoHS: RoHS Compliant Details
Brand: Cornell Dubilier - CDE
Capacitance: 680 uF
Voltage Rating DC: 250 V
Tolerance: 20 %
ESR: 219 mOhms
Ripple Current: 2.5 A
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Load Life: 2000 h
Diameter: 30 mm
Length: 37 mm
Lead Spacing: 10 mm
Dissipation Factor DF: 20
Leakage Current: 4 mA
Number of Pins: 2
Product: Aluminum Electrolytic Capacitors
Series: 380LQ
Termination Style: Snap In
Test Frequency: 120 Hz
Type: Compact, High Capacitance, Snap-In Aluminum Capacitors
Part # Aliases: EET-UQ2E681CA EET-UQ2E681JA


ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
