Pagină de start>Componente electronice active>Tranzistoare>Tranzistoare bipolare>2SA1943, SI-P, 250V, 17A, ON SEMICONDUCTOR

Mareste

2SA1943, SI-P, 250V, 17A, ON SEMICONDUCTOR

Denumire Produs: 2SA1943OTU, Fairchild Semiconductor

COD: 73489

Preț orientativ: 33,60 RON

  2SA1943OTU  Bipolar (BJT) Single Transistor, PNP, -250 V, 30 MHz, 150 W, -17 A, 80 hFE

Manufacturer:
oHS: RoHS Compliant Details
Configuration: Single
Transistor Polarity: PNP
Collector- Base Voltage VCBO: 230 V
Collector- Emitter Voltage VCEO Max: 230 V
Emitter- Base Voltage VEBO: 5 V
Maximum DC Collector Current: 17 A
Gain Bandwidth Product fT: 30 MHz
Maximum Operating Temperature: + 150 C
Mounting Style: Through Hole
Package / Case: TO-264-3
Brand: Fairchild Semiconductor
Continuous Collector Current: 13 A
DC Collector/Base Gain hfe Min: 55 at 1 A at 5 V
Maximum Power Dissipation: 150000 mW
Minimum Operating Temperature: - 50 C
Series: 2SA1943


Inlocuire pentru: 2SA1302, 2SA1943, 2SA1987, 2SA1265





ATENTIE: Imaginile produselor au numai titlu indicativ si pot diferi de imaginea reala a produselor. Acest lucru nu schimba caracteristicile lor de baza.
